Diaphragm Pump Graco Husky 515 Size 1/2 Inch, Jual GRACO Husky 515 Diaphragm Pump

Diaphragm Pump Graco Husky 515 Size 1/2 Inch
GRACO Husky 515 AC 1/2 in NPT Standard Pump,
PP Center Section, AC Seats, BN Balls & BN Diaphragm
Part No. D51277
Technical Specifications :
Maximum fluid working pressure : 100 psi (0.7 MPa, 7 bar)
Air pressure operating range : 30 to 100 psi (0.2 to 0.7 MPa, 2.1 to 7 bar )
Maximum air consumption : 28 scfm (0.672 cubic meters/min.)
Maximum free flow delivery (1/2 in. ports) : 15 gpm (57 l/min)
Maximum pump speed : 400 cpm
Gallons (Liters) per cycle : 0.04 (0.15)
Maximum suction lift (water w/buna balls) : 15 ft (4.5 m) dry,
                                            25 ft (7.6 m) wet
Maximum size pumpable solids : 3/32 in. (2.5 mm)
Sound power level (measured per ISO standard 9614--2)
At 70 psig (0.48 MPa, 4.8 bar) at 50 cycles per minute : 77 dBa
At 100 psig (0.7 MPa, 7 bar) at maximum cycles per minute : 95 dBa
Sound pressure level (measured 1 meter from pump)
At 70 psig (0.48 MPa, 4.8 bar) at 50 cycles per minute : 67 dBa
At 100 psig (0.7 MPa, 7 bar) at maximum cycles per minute : 85 dBa
Air inlet size : 1/4 npt(f)
Air exhaust port size : 3/8 npt(f)
Fluid inlet size : 3/4 in. npt(f)
Fluid outlet size : 1/2 and 3/4 in. npt(f)
Wetted parts : Groundable Acetal, Buna–N, PTFE
Non–wetted parts : Polypropylene, Stainless Steel, Polyester and Aluminum, Nickel Plated Brass
Weight (approximate) : 7.8 lb (3.5 kg)
