Diaphragm Pump Graco Husky 2150 ukuran 2 inch , Jual Diaphragm Pump Graco

Graco Husky 2150 Air-Operated Diaphragm Pumps
2-inch AODD pump for fluid transfer applications. For professional use only.
See Models on page 3 for a list of pump models, descriptions, and approvals.
Technical Specifications
PN : DF3525
Husky 2150
Size : 2 Inch
Maximum fluid working pressure : 120 psi (0.8 MPa, 8 bar)
Air pressure operating range: 20- 120 psi (0.14- 0.8 MPa, 1.4- 8 bar)
Maximum air consumption: 175 scfm
Air consumption at 70 psi/60 gpm : 60 scfm (see chart)
Maximum free-flow delivery : 150 gpm (568 l/min)
Maximum pump speed : 145 cpm
Gallons (Liters) per cycle : 1.03 (3.90)
Maximum suction lift : 18 ft (5.48 m) wet or dry
Maximum size pumpable solids : 1/4 in. (6.3 mm)
* Maximum noise level at 100 psi and 50 cpm: 90 dBa
* Sound power level : 103 dBa
* Noise level at 70 psi and 50 cpm : 85 dBa
Maximum operating temperature : 150°F (65.5°C)
Air inlet size : 1/2 npt(f)
Fluid inlet size : 2” Raised Face Flange
Fluid outlet size : 2” Raised Face Flange
Wetted parts : Vary by Model. See pages 29- 31
Non-wetted external parts : aluminum, 302 and 316 stainless steel, polyester (labels)Weight
Polypropylene pumps with Aluminum center section : 49 lb (22 kg)
Conductive Polypropylene pumps with Aluminum center section : 53 lb (24 kg)
PVDF pumps with Aluminum center section : 68 lb (31 kg)
Polypropylene pumps with stainless steel center section : 71 lb (32 kg)
Conductive Polypropylene pumps with stainless steel center section : 75 lb (34 kg)
PVDF pumps with stainless steel center section : 90 lb (41 kg)
